It’s hard to pick a favourite, isn’t it! The thrill of a Crafty Carbon isn’t just about the power, travel or range.

No one’s denying this lineup is a true statement of performance: Bosch CX Gen5 motor, a removable 800Wh battery, and now a seamlessly integrated Kiox 400 display flush-mounted in the top tube.

But don’t forget the colours! Because each one tells a different story.

Specifications

• Frame

  Crafty Stealth Air full Carbon front triangle, Stealth Alloy rear triangle, Updated Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.





  Sizes

  S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm




  Rear shock

  Fox Float-X LV Performance, 185x55mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 30x8mm bottom bushings





  Shock settings

  CS40 compression, RL70 rebound, Rezi B40, LML, 0.2 volume spacer




  Fork

  Fox 38 29 Float GRIP Performance, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload





  Headset

  Acros custom ZS56/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock




  Stem

  Onoff S6 30mm 0º, 6061 forged alloy + CNC, 31.8mm barbore





  Handlebar

  Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.




  Grips

  Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size





  Seatpost

  Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 140-115mm (388-235mm), M size: 160-135mm (428-255mm), ML size: 180-155mm (468-275mm), L size: 210-185mm (528-305mm), XL size: 210-185mm (528-305mm)




  Saddle

  Ergon SM-10





  Front brake

  Sram Maven Base, 18 and 19.5-millimeter 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads




  Rear brake

  Sram Maven Base, 18 and 19.5-millimeter 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads





  Brake lever

  Sram Maven Base , SwingLink and lever pivot bushings, tools-free reach adjust




  Rims

  Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes





  Spokes

  Mavic J-bend double butted, contactless lacing




  Front hub

  Mavic, Boost 15x110mm, IS 6 bolts





  Rear hub

  Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub




  Front tire

  Maxxis Assegai 29x2.5WT, tubeless ready, 3C Maxx Grip compound, EXO+ protection, 60TPI, folding bead





  Rear tire

  Maxxis Minion DHR II 29x2.5 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 2x120TPI, folding bead




  Crankset

  Race Face Aeffect-R ebike, 160mm





  Rings

  Sram Eagle 34T T-Type, direct mount, steel, CL55




  Chain

  Sram GX Eagle T-Type, 12s, Powerlock





  Rear derrailleur

  Sram S1000 Eagle AXS T-Type, 12s




  Shift levers

  Sram Eagle AXS Pod MMX, 12s





  Casette

  Sram XS-1270, 10-52T, T-Type, 12s




  Weight

  23,9 kg





  Display

  Kiox 400 / Bosch Mini Remote




  Motor

  Bosch Performance Line CX (25Km/h) SMART SYSTEM (BDU384Y)





  Battery

  Bosch Powertube 800Wh
