Mondraker SUMMUM RR Mullet Silver Flash Frameset
Mondraker SUMMUM RR Mullet Silver Flash Frameset
  • Home
  • products
  • Mondraker SUMMUM RR Mullet Silver Flash Frameset

Mondraker SUMMUM RR Mullet Silver Flash Frameset

Mondraker
£ 2,799.00
Tax included.

Pairs well with

SUMMUM: WRITTEN IN HISTORY

An all-new Summum that’s taken the longest to develop, evolved and improved in all areas. A machine that’s been race crafted over the past two years.



27 ADJUSTMENTS FOR THE PERFECT SET-UP


For those most skilled riders who prefer to further customize the geometry or adapt this new bike to certain courses or personal preferences you will find up to 27 possible configurations thanks to adjustable headset cups, a lower shock-mount flip chip, and adjustable rear dropouts.



Headset-Reach

Adjust with three positions, standard and +/-5mm.



Lower shock-mount flip chip

To adjust bottom bracket height +/-5mm, and angles +/-0.35°



Adjustable rear dropouts

+/-5mm (450mm or 460mm options) from 455mm standard chainstay length.



In 2026 the UCI World Championships will return to Val di Sole, Italy.

The same venue Mondraker conquered in 2016, with a clean sweep of the World Championships elite men’s DH podium thanks to Hart, Greenland and Payet. The most impressive achievement ever by a bicycle brand and by a single bicycle model, and one that remains unmatched to this day. This new Summum will once again be in the starting hut to try to repeat this feat, 10 years on.

Specifications

Sizes

M / L / XL MX


Rear shock

Rock Shox Vivid Coil Ultimate, 225x75mm, Linear rebound, Medium compression, spring preload. Trunnion top mount, 30x8mm bottom bushings


Shock settings

Medium compression, linear rebound. Spring rate: M size 450 lbs, L size 500 lbs, XL size 550 lbs



Headset

Onoff DH ARS (Adjustable Reach System) 1-1/8", 1-1/8" steerer tube, 41x30x7 45ºx45º sealed bearings, reach geometry kit cups (+-5mm)


Stem

Onoff S9 DH CNC Integrated, 45-50mm adjustable length, 10mm rise, 31.8mm barbore, 7075 alloy, 2x6mm spacer


Derailleur hanger

Sram UDH


Others

*Geometry kit included: +- 5mm headset cups, Lower shock mount flip chip, +5mm dropout, -5mm dropo
