Frame size
|
S | M | L | XL | |
|---|---|---|---|---|---|
| A | Seattube length | 380mm 14.96" | 420mm 16.54" | 450mm 17.72" | 490mm 19.29" |
| B | Toptube length | 595mm 23.43" | 615mm 24.21" | 640mm 25.20" | 660mm 25.98" |
| C | Bottom bracket drop | -25mm -0.98" | -25mm -0.98" | -25mm -0.98" | -25mm -0.98" |
| D | Bottom bracket height | 348mm 13.70" | 348mm 13.70" | 348mm 13.70" | 348mm 13.70" |
| E | Chainstay length | 450mm 17.72" | 450mm 17.72" | 450mm 17.72" | 450mm 17.72" |
| F | Seat tube angle | 72,6º | 72,6º | 72,6º | 72,6º |
| G | Effective seattube angle | 76.5° | 76.5° | 76.5° | 76.5° |
| H | Headtube angle | 64.5º | 64.5º | 64.5º | 64.5º |
| I | Fork Offset | 44mm 1.73" | 44mm 1.73" | 44mm 1.73" | 44mm 1.73" |
| J | Wheelbase | 1235mm 48.62" | 1255mm 49.41" | 1275mm 50.20" | 1295mm 50.98" |
| K | Headtube length | 110mm 4.33" | 110mm 4.33" | 130mm 5.12" | 140mm 5.51" |
| L | Reach | 450mm 17.72" | 470mm 18.50" | 495mm 19.49" | 515mm 20.28" |
| M | Stack | 626mm 24.65" | 626mm 24.65" | 642mm 25.28" | 650 mm 25.59" |
UPDATED ZERO SUSPENSION SYSTEM
This new Light e-MTB category has led us to develop a new suspension kinematic specifically conceived for this type of bike.
The NEAT’s suspension system showcases a new kinematic configuration in which the shock is located lower down in the frame, with a more compact, lighter and stiffer swingarm. This optimisation provides greater sensitivity at the start of the shock’s stroke and better overall shock-absorption deeper into its travel.
The more compact swingarm design allows for longer seatposts, more space between water bottles, tools and range extenders, and a better balance between weight and rigidity.
NATURAL FEEL TQ-HPR50 SYSTEM
The TQ-HPR50 system comprises a very compact motor which we’ll talk about later on, a 360Wh removable internal battery located in the downtube, a 2” display fitted into the top tube and an optional 160Wh range extender. The whole system weighs in at 3.9Kg, 1850g the motor and 1830g the 360Wh battery. The optional TQ range extender weighs 950g.
Combining 3 natural-feeling levels of assistance and running almost silently, the TQ-HPR50 provides up to 300W of power and 50Nm of torque. A multitude of variables will always come into play when talking about range, but a rider of average weight (around 75Kg) can expect to be able to complete a ride of between 3-4 hours, with more than 1000m of altitude gain, switching between ECO and MID modes, and ride anywhere from 40 to 50km. The optional range extender can increase that by up to 50%.
THE BALANCED GEOMETRY OF NEAT
NEAT comes with category specific geometry and counts on the best that the FOXY CARBON and CRAFTY CARBON offer in their respective categories.
64.5º head angle. As slack as a FOXY CARBON in the LOW setting.
76.5º effective seat tube angle. 1º steeper than the FOXY CARBON.
450mm chainstays. 5mm shorter than the CRAFTY CARBON and 5mm longer than the FOXY CARBON.
BB height of 348mm (-25mm drop). The perfect height for an ebike of its class.
Reach of 450/470/495/515mm (S/M/L & XL). Reach figures inspired by the FOXY CARBON and CRAFTY CARBON.
ONE APP, INFINITE POSSIBILITIES
The scope of adjustment available to fine-tune the parameters of the TQ-HPR50 motor is one of the characteristics that best fits our philosophy here at Mondraker. Via the TQ E-Bike smartphone app and Bluetooth connection you can control all the parameters of the motor to an almost limitless extent.
There are 3 modes available to let you quickly flick through the different levels of assistance provided by the motor: ECO, MID and HIGH. Within each of these modes you have a further 3 parameters which can be individually adjusted via the app: Max power, Assistance, and Pedal Response.
-Maximum Power: Adjustable between 30W and 300W (the maximum amount of power provided by the motor at maximum performance).
-Assistance: The percentage max assistance level of the motor, adjustable from 25% up to 200%.
-Pedal Response: The regulation of the delivery of power from the moment you first start pedalling.
The possibility of being able to regulate each mode individually, each mode being adjustable by a further three parameters, means that not only is the number of possible permutations enormous, but more importantly that you can set up your preferences to a tee, thus improving your riding experience.
Light E-MTB Yes, But Mondrakers Way
After several years of taking stock of the state of the market and deciding that it just didn’t convince us, we developed the NEAT project utilizing an innovative system of motor and battery, more than capable of satisfying the needs of this sector and with which we felt we could identify as riders.
We understood that weight was a key factor for this new platform, but we couldn’t let itcompromise the performanceof the whole package, the suspension travel or the handling.
BEST OF BOTH WORLDS
Mondraker has managed to merge the best of both worlds by blending our two category leading bikes: the Enduro FOXY CARBON and e-MTB Enduro CRAFTY CARBON. 2024 then, sees the arrival of NEAT. A model with unmistakable aesthetics, characteristics and identity which sets a benchmark in this new category.
DEFINING OUR LIGHT E-MTB
NEAT is our vision of what the Light e-MTB category should be, while bringing the character which defines all Mondraker bikes into the mix.
NEAT is the product of our desire to blur the line between traditional MTBs and full power eMTBs, creating a bike which truly offers the best of both worlds. A 150mm enduro bike with a 160mm fork, the lower limit travel for maximum performance. Light, but without sacrificing anything in the process.
NEAT = ANY TYPE OF RIDER AND ANY TYPE OF RIDING
NEAT is a new category of bike for Mondraker. A category that was until now unrealised, falling between the flexibility of a FOXY CARBON and the capability of a CRAFTY CARBON. NEAT walks the perfect line between the two, for any type of rider and any type of riding.
-Riders who are making the move from a traditional mountain bike or who are just starting out on an ebike: NEAT lets you ride faster, farther, and descend with more aplomb and more safely than ever before, without sacrificing the feelings and handling of a traditional non-ebike MTB.
-Riders who are making the move from a full power ebike: NEAT is going to make your ride fleeter of foot, more agile, and faster reacting on climbs without giving up the traits of an ebike on the descents.
